Tuote

Thermaltake Toughpower PF1 power supply unit 850 W 24-pin ATX ATX Black

Tuotetiedot
SKUZDLTHEOBU0093
Design
Product colourBlack
Fan locationTop
On/off switchYes
Number of fans1 fan(s)
Fan diameter12 cm
Power
Combined power (-12V)3.6 W
Power protection featuresOver current
Total power850 W
Power Factor Correction (PFC) typeActive
Max output current (+3.3V)20 A
Combined power (+12V)744 W
AC input voltage100 - 240 V
Hold time16 ms
Max output current (+5V)20 A
Combined power (+3.3V)100 W
Max output current (+12V)62 A
Combined power (+5Vsb)12.5 W
Input current10 A
Max output current (-12V)0.3 A
AC input frequency50 - 60 Hz
Max output current (+5Vsb)2.5 A
Peak power900 W
Operational conditions
Operating temperature (T-T)5 - 50 °C
Storage temperature (T-T)-40 - 55 °C
Storage relative humidity (H-H)10 - 95%
Operating relative humidity (H-H)20 - 85%
Weight & dimensions
Width150 mm
Depth140 mm
Height86 mm
Performance
Noise level27.8 dB
Bearing technologyHDB
Silent modeYes
Power supply unit (PSU) form factorATX
Mean time between failures (MTBF)120000 h
80 PLUS certification80 PLUS Platinum
Packaging content
Cables includedAC, CPU, PCIe, Peripheral (Molex), SATA
Ports & interfaces
PCI Express power connectors (6+2 pin)4
Peripheral (Molex) power connectors (4-pin)4
Floppy disk drive connectorYes
SATA power cable length150 mm
Motherboard power cable length60 cm
Cabling typeFully-Modular
Number of SATA power connectors3
Peripheral (Molex) power cable length150 mm
CPU power connector (4+4 pin)Yes
Floppy disk drive cable length15 cm
PCI Express power connectors (6-pin)2
CPU power cable length65 cm
Motherboard power connector24-pin ATX
Logistics data
Harmonized System (HS) code84733020
