Tuote

Intel Core i7-14700K processor 33 MB Smart Cache Box

Tuotetiedot
SKUPROINTCI70205
Technical details
Launch dateQ4'23
OpenCL version3.0
StatusLaunched
Processor
Processor codenameRaptor Lake
SteppingB0
Processor familyIntel® Core™ i7
Cooler includedNo
Efficient cores12
Processor cache typeSmart Cache
Processor cores20
Processor base power125 W
Processor modeli7-14700K
Performance-core boost frequency5.5 GHz
Maximum number of DMI lanes8
Processor operating modes64-bit
Processor threads28
Processor manufacturerIntel
Memory bandwidth supported by processor (max)89.6 GB/s
Performance-core base frequency3.4 GHz
Processor generationIntel® Core™ i7 (14th gen)
Performance cores8
Processor socketLGA 1700
Processor cache33 MB
Maximum turbo power253 W
BoxYes
Processor ARK ID236783
Graphics
On-board graphics card DirectX version12.0
Discrete graphics card modelNot available
Number of execution units32
On-board graphics card modelIntel UHD Graphics 770
On-board graphics card maximum resolution (eDP - Integrated Flat Panel)5120 x 3200 pixels
On-board graphics card refresh rate at maximum resolution (HDMI)60 Hz
On-board graphics card refresh rate at maximum resolution (DisplayPort)60 Hz
On-board graphics cardYes
On-board graphics card maximum resolution (DisplayPort)7680 x 4320 pixels
On-board graphics card maximum resolution (HDMI)4096 x 2160 pixels
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)120 Hz
Discrete graphics cardNo
On-board graphics card base frequency300 MHz
Multi-Format Codec Engines2
On-board graphics card OpenGL version4.5
On-board graphics card outputs supportedHDMI 2.1
On-board graphics card ID0xA780
Number of displays supported (on-board graphics)4
On-board graphics card dynamic frequency (max)1600 MHz
Features
Embedded options availableNo
Thermal Monitoring TechnologiesYes
PCI Express configurations1x16+1x4
PCI Express slots version5.0
CPU configuration (max)1
Maximum number of PCI Express lanes20
Export Control Classification Number (ECCN)5A992C
Direct Media Interface (DMI) Revision4.0
Supported instruction setsSSE4.1
Commodity Classification Automated Tracking System (CCATS)740.17B1
Idle StatesYes
Scalability1S
Thermal solution specificationPCG 2020A
Use conditionsPC/Client/Tablet
Execute Disable BitYes
Market segmentDesktop
Memory
Non-ECCYes
Memory types supported by processorDDR5-SDRAM
Maximum internal memory supported by processor192 GB
Memory bandwidth (max)89.6 GB/s
ECCYes
Memory channelsDual-channel
Operational conditions
Tjunction100 °C
Weight & dimensions
Processor package size45 x 37.5 mm
Processor special features
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Clear Video HD Technology (Intel® CVT HD)Yes
Enhanced Intel SpeedStep TechnologyYes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel® Turbo Boost Technology2.0
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0Yes
Intel® OS GuardYes
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel® Speed Shift TechnologyYes
Intel VT-x with Extended Page Tables (EPT)Yes
Intel® Boot GuardYes
Intel® Deep Learning Boost (Intel® DL Boost) on CPUYes
Intel® Thread DirectorYes
Intel® Volume Management Device (VMD)Yes
Intel 64Yes
Mode-based Execute Control (MBE)Yes
Intel Turbo Boost Max Technology 3.0Yes
Intel® Quick Sync Video TechnologyYes
Intel® Control-flow Enforcement Technology (CET)Yes
Intel Virtualization Technology (VT-x)Yes
Intel® Secure KeyYes
Intel® Turbo Boost Max Technology 3.0 frequency5.6 GHz
Intel® Standard Manageability (ISM)Yes
Other features
Maximum internal memory192 GB
L2 cache28672 KB
Graphics outputeDP 1.4b, DP 1.4a, HDMI 2.1
Logistics data
Harmonized System (HS) code8542310001
Safety warning
WarningsEnsure that the processor is adequately cooled to prevent overheating.
