Tuote

Intel Core i7-12700KF processor 25 MB Smart Cache Box

Tuotetiedot
SKUPROINTCI70198
Technical details
Launch dateQ4'21
StatusLaunched
Target marketGaming, Content Creation
Processor
Processor base power125 W
Maximum turbo power190 W
Processor generation12th gen Intel® Core™ i7
BoxYes
Maximum number of DMI lanes8
Performance-core boost frequency4.9 GHz
Performance-core base frequency3.6 GHz
Memory bandwidth supported by processor (max)76.8 GB/s
Performance cores8
Efficient cores4
Bus typeDMI4
Processor cache typeSmart Cache
Processor ARK ID134595
Processor familyIntel® Core™ i7
Processor codenameAlder Lake
Processor socketLGA 1700
Processor modeli7-12700KF
Processor cache25 MB
Processor manufacturerIntel
Processor cores12
Processor operating modes64-bit
Component forPC
Processor threads20
Graphics
On-board graphics cardNo
Discrete graphics cardNo
On-board graphics card modelNot available
Discrete graphics card modelNot available
Features
Harmonized System (HS) code8542310001
Use conditionsPC/Client/Tablet
Market segmentDesktop
Thermal solution specificationPCG 2020A
Commodity Classification Automated Tracking System (CCATS)G167599
Export Control Classification Number (ECCN)5A992CN3
Maximum number of PCI Express lanes20
PCI Express slots version5.0
Thermal Monitoring TechnologiesYes
Embedded options availableNo
CPU configuration (max)1
PCI Express configurations1x16+1x4
Idle StatesYes
Execute Disable BitYes
Supported instruction setsSSE4.2
Scalability1S
Memory
Memory types supported by processorDDR4-SDRAM
Memory bandwidth (max)76.8 GB/s
Memory channelsDual-channel
Maximum internal memory supported by processor128 GB
Operational conditions
Tjunction100 °C
Weight & dimensions
Processor package size45 x 37.5 mm
Processor special features
Intel® Boot GuardYes
Mode-based Execute Control (MBE)Yes
Intel® Volume Management Device (VMD)Yes
Intel® Turbo Boost Max Technology 3.0 frequency5 GHz
Intel® Control-flow Enforcement Technology (CET)Yes
Intel® Speed Shift TechnologyYes
Intel® Deep Learning Boost (Intel® DL Boost) on CPUYes
Intel Turbo Boost Max Technology 3.0Yes
Intel® Thread DirectorYes
Intel VT-x with Extended Page Tables (EPT)Yes
Intel 64Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel Virtualization Technology (VT-x)Yes
Enhanced Intel SpeedStep TechnologyYes
Intel® OS GuardYes
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Secure KeyYes
Intel® Optane™ Memory ReadyYes
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel® Turbo Boost Technology2.0
Other features
Maximum internal memory128 GB
Safety warning
WarningsEnsure that the processor is adequately cooled to prevent overheating.
