Intel Core i7-12700F processor 25 MB Smart Cache Box

Tuotetiedot
SKUPROINTCI70191
Technical details
Target marketGaming, Content Creation
Launch dateQ1'22
StatusLaunched
Processor
Processor familyIntel® Core™ i7
Processor codenameAlder Lake
Cooler includedYes
Processor operating modes64-bit
Processor generation12th gen Intel® Core™ i7
Processor base power65 W
Processor manufacturerIntel
Performance-core base frequency2.1 GHz
Maximum number of DMI lanes8
Processor threads20
Processor modeli7-12700F
Performance-core boost frequency4.8 GHz
Processor cache typeSmart Cache
Processor cache25 MB
BoxYes
Efficient cores4
Bus typeDMI4
Memory bandwidth supported by processor (max)76.8 GB/s
Performance cores8
Processor cores12
Processor socketLGA 1700
Maximum turbo power180 W
Processor ARK ID134592
Graphics
Discrete graphics card modelNot available
On-board graphics card modelNot available
Discrete graphics cardNo
On-board graphics cardNo
Features
PCI Express configurations1x16+1x4
CPU configuration (max)1
Embedded options availableNo
Thermal Monitoring TechnologiesYes
PCI Express slots version4.0
Export Control Classification Number (ECCN)5A992CN3
Supported instruction setsSSE4.1
Commodity Classification Automated Tracking System (CCATS)G167599
Scalability1S
Idle StatesYes
Execute Disable BitYes
Direct Media Interface (DMI) Revision4.0
Maximum number of PCI Express lanes20
Use conditionsPC/Client/Tablet
Market segmentDesktop
Memory
Non-ECCYes
Maximum internal memory supported by processor128 GB
Memory types supported by processorDDR4-SDRAM
Memory channelsDual-channel
Memory bandwidth (max)76.8 GB/s
Operational conditions
Tjunction100 °C
Weight & dimensions
Processor package size45 x 37.5 mm
Processor special features
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Turbo Boost Technology2.0
Enhanced Intel SpeedStep TechnologyYes
Intel® Standard Manageability (ISM)Yes
Mode-based Execute Control (MBE)Yes
Intel® Boot GuardYes
Intel® Deep Learning Boost (Intel® DL Boost) on CPUYes
Intel® Speed Shift TechnologyYes
Intel Turbo Boost Max Technology 3.0Yes
Intel® Volume Management Device (VMD)Yes
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel® Thread DirectorYes
Intel® Secure KeyYes
Intel® Optane™ Memory ReadyYes
Intel® OS GuardYes
Intel 64Yes
Intel® Turbo Boost Max Technology 3.0 frequency4.9 GHz
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0Yes
Intel® Control-flow Enforcement Technology (CET)Yes
Intel VT-x with Extended Page Tables (EPT)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel Virtualization Technology (VT-x)Yes
Other features
Maximum internal memory128 GB
Logistics data
Harmonized System (HS) code85423119
Safety warning
WarningsEnsure that the processor is adequately cooled to prevent overheating.
